| PRODUCT INFORMATION | |
| Sensor type | Dräger CatEx, XXS |
| Detected gases | Oxygen (O2), Hydrogen sulfide (H2S), Carbon monoxide (CO), EX - explosive gas (CH4, methane)* * The type of detected gases depends on the configuration of the meter |
| Alarm signaling | Optical 360°: 3 red LEDs (gas alarms), 3 yellow LEDs (device alarms) Acoustic: multi-tone >90dB / 0.3m Vibrating alert |
| Calibration signaling | Yes |
| Display | Large, illuminated, linguistically neutral |
| Memory | Optimized data compression with high accuracy and high capacity internal memory* * Typically the data compression ratio is > 90% compared to a standard adjustable interval logger. |
| Housing | Protection class IP68 |
| Sockets, connectors, ports | Bluetooth 5.0 allows you to download events to your computer for more detailed analysis |
| Additionally included | User manual, power supply and charging set: NiMH battery, charging module, power adapter |
| CARBON MONOXIDE (CO) | |
| Measurement range | 0 – 2000 ppm |
| Alarm threshold A1/A2 (standard) | 30 / 60 ppm |
| EXPLOSIVE GASES (CH4, METHANE) | |
| Measurement range | 0 ~ 100% LEL |
| Alarm threshold A1/A2 (standard) | 20 / 40% LEL |
| OXYGEN (O2) | |
| Measurement range | 0 – 25 Vol.-% |
| Alarm threshold A1/A2 (standard) | 19 / 23 Vol.-% |
| HYDROGEN SULFIDE (H2S) | |
| Measurement range | 0 – 100 ppm |
| Alarm threshold A1/A2 (standard) | 5 / 10 ppm |
| POWER | |
| Power source | Built-in rechargeable NiMH battery |
| Battery life | >100 h w/o Ex sensor >12 h with Bluetooth module ON |
| WORKING AND STORAGE CONDITIONS | |
| Working conditions | Temperature: -20 ~ 50°C Humidity: 10 ~ 95% RH (for short periods 5 ~ 95% RH) Ambient pressure: 700 ~ 1300 hPa (measurement), 800 ~ 1100 hPa (use in potentially explosive atmospheres) ) |
| QUALITY AND SAFETY | |
| Certificates and approvals | CE mark, cCSAus, IECEx, ATEX |
